The gamma-ray monitoring buoy system is primarily used to monitor radioactivity levels in waters near nuclear facilities to ensure the safe operation of nuclear facilities. The buoy is equipped with gamma radiation monitoring instruments to monitor the level of gamma radiation in seawater in real time. Through the nuclide spectroscopy monitoring system, the buoy is able to analyze radionuclides in seawater and identify and quantify different radioisotopes . Thus, the content of radioactive substances in seawater is assessed , and the measured data is transmitted back to the ground measurement and control terminal in real time through 4G or wireless communication line. The gamma-ray monitoring buoy system can be arranged in the offshore nuclear radiation environment and nuclear emergency application scenarios. While completing the in-situ monitoring of radioactive substances, it can combine the global positioning system and threshold alarm algorithm to determine the location information and radiation dose intensity and other information of the water where radioactive substances are located, so as to obtain various detected data conveniently and quickly. Help decision makers to take corresponding measures in a timely manner.
Product Specifications
|
Diameter (mm) |
1200 |
2300 |
2600 |
3200 |
|
Focal plane (mm) |
1300 |
2500 |
3000 |
3500 |
|
Reserve buoyancy (kg) |
200 |
2490 |
3000 |
5000 |
|
Weight (kg)* |
250 |
1200 |
2000 |
2200 |
|
Water line position (mm) |
1100 |
1500 |
1500 |
1800 |
|
Full height (mm) |
2400 |
4000 |
4500 |
5000 |
|
Name |
Gamma ray monitoring buoys |
||||||||||||||||||||||||||||||||||
|
Power supply system |
Storage battery |
12VDC80AH/80-200AH |
|||||||||||||||||||||||||||||||||
|
Solar panels |
12v/80W-400W |
||||||||||||||||||||||||||||||||||
|
Position indication |
Warning lights; GPS location; AIS |
||||||||||||||||||||||||||||||||||
|
Data acquisition |
4G, 5G, wireless communication |
||||||||||||||||||||||||||||||||||
|
Support monitoring sensor parameters |
Dissolved oxygen measuring range :0-20mg/L Electrical conductivity range :0-5000uS/cm pH range: 0-14 pH, Ammonia nitrogen range :0-100mg/ Chlorophyll range :0-500ug/L Wave height: Range: 0-25m Wave period: Range: 1.5-25s Wave direction: Range: 0-360 ° Resolution: 1° Ocean current velocity Measuring range 0-300cm /s Resolution 0.1mm/s Accuracy ±0.15cm/s Flow Direction Range 0-360° Resolution 0.01° |
||||||||||||||||||||||||||||||||||
|
Additional customization: visibility, weather |
|||||||||||||||||||||||||||||||||||
Application Scenarios
1. Ocean Wind farm
2. Navigational Warnings
3. Ecological disaster warning
Packaging and Transportation
Reasonable design of packaging, wooden box packaging can reliably protect the stone, reduce the cargo damage in the logistics process, to ensure the safety of stone products
