The typhoon monitoring buoy is usually composed of a buoy body and a monitoring sensor chain. The buoy is equipped with multiple sensors. The daily sampling frequency is usually once every 30 minutes, but it can be increased to once every 10 minutes during the typhoon impact . These typhoon monitoring buoys also support Beidou communications and wireless networks, and the sampling frequency can be increased by remote command . At the same time, the data of wind direction, wind speed, pressure and sea temperature near the typhoon center can be obtained in real time, which can provide important observation basis for forecasters to forecast the typhoon intensity and path . These buoys can also monitor a variety of parameters of the ocean and atmosphere, including wind field 2 meters offshore, air temperature, humidity, air pressure, sea surface temperature and multi-layer temperature, pressure and salinity within 100 meters underwater . The buoys will provide enough time for relevant departments to take countermeasures and serve as disaster early warning.
Product Specifications
|
Diameter (mm) |
900 |
1800 |
2300 |
2600 |
|
Focal plane (mm) |
1200 |
2000 |
2500 |
3000 |
|
Reserve buoyancy (kg) |
200 |
1401 |
2490 |
3000 |
|
Weight (kg)* |
200 |
850 |
1200 |
2000 |
|
Water line position (mm) |
1100 |
1200 |
1500 |
1500 |
|
Full height (mm) |
2000 |
3000 |
4000 |
4500 |
|
Name |
Typhoon Monitoring buoy |
||||||||||||||||||||||||||||||||||
|
Power supply system |
Storage battery |
12VDC80AH/80-200AH |
|||||||||||||||||||||||||||||||||
|
Solar panel |
12v/80W-400W |
||||||||||||||||||||||||||||||||||
|
Position indication |
Warning lights; GPS location; AIS |
||||||||||||||||||||||||||||||||||
|
Data acquisition |
4G, 5G, wireless communication, Lora, |
||||||||||||||||||||||||||||||||||
|
Support monitoring sensor parameters |
Dissolved oxygen measuring range :0-20mg/L Turbidity range :0-1000NTU Conductivity range :0-5000uS/cm pH range: 0-14 pH, Ammonia nitrogen range :0-100mg/ UVCOD measuring range :0-400mg/L Chlorophyll range :0-500ug/L Wave height: Range: 0-25m Accuracy: <±3% Wave period: Range: 1.5-25s Accuracy: <±0.2 seconds Wave direction: Range: 0-360 ° Resolution: 1° Measuring range 0-300cm /s Resolution 0.1mm/s Accuracy ±0.15cm/s Relative accuracy ±1% reading Flow Direction Range 0-360° magnetic Angle Resolution 0.01° |
||||||||||||||||||||||||||||||||||
|
Additional customization: visibility, weather |
|||||||||||||||||||||||||||||||||||
Application Scenarios
1. Marine resource development
2. Meteorological monitoring
3. Nuclear radiation monitoring
Packaging and Transportation
Reasonable design of packaging, according to the size, characteristics and quantity of the product, design a reasonable carton, wooden box structure to ensure that the product is fully supported and protected inside the wooden box. Lining materials such as foam are used inside the wooden box to reduce the vibration and extrusion of the products in the process of shipping.
