Detection buoy is also a kind of ocean monitoring buoy, which is composed of battery solar power supply, data monitoring and acquisition, data transmission and anchor. The main functions and functions includes the following 4 aspects:
real-time monitoring of water quality and Marine environment parameters : the detection buoy can monitor the key water quality parameters in the water body in real time, such as dissolved oxygen, pH value, temperature, turbidity, ammonia nitrogen, nitrate, temperature, visibility, salinity, water level, tide, wave and so on . These data are crucial for understanding changes in water quality and Marine ecosystems.
Early warning of pollution and disaster : Equipped with a variety of high-precision sensors, the detecting buoys can automatically give an alarm when abnormal water quality or Marine environmental parameters are detected, and transmit the warning information to relevant departments and managers through wireless communication technology. The real-time monitoring and early warning mechanism can help timely discover and deal with environmental pollution problems, prevent water quality deterioration and pollution spread, as well as monitor storm surge, tsunami and other natural disasters, and improve early warning and forecasting capabilities .
Data recording and analysis : The detection buoy can automatically record historical data and store it in an internal memory or a remote server. These data provide valuable information resources for environmental protection authorities to facilitate data analysis, trend prediction and scientific decision-making. In-depth analysis of water quality or Marine data can reveal the rules and causes of changes, and provide a basis for formulating environmental protection measures .
Multi-functional application scenario : There are many types of detection buoys, which are suitable for different application scenarios. For example, weather buoys are used to measure wind speed, wind direction, wave height, etc., and scientific research buoys are used to collect and record Marine environmental data.
Product Specifications
|
Diameter (mm) |
800 |
1800 |
2600 |
3200 |
|
Focal plane (mm) |
1000 |
2000 |
3000 |
3500 |
|
Reserve buoyancy (kg) |
200 |
1401 |
3000 |
5000 |
|
Weight (kg)* |
200 |
850 |
2000 |
2200 |
|
Water line position (mm) |
1100 |
1200 |
1500 |
1800 |
|
Full height (mm) |
1000 |
3000 |
4500 |
5000 |
|
Name |
Detection buoy |
||||||||||||||||||||||||||||||||||
|
Power supply system |
Storage battery |
12VDC80AH/80-200AH |
|||||||||||||||||||||||||||||||||
|
Solar panels |
12v/80W-400W |
||||||||||||||||||||||||||||||||||
|
Position indication |
Warning lights; GPS location; AIS |
||||||||||||||||||||||||||||||||||
|
Data acquisition |
4G, 5G, wireless communication, Lora, |
||||||||||||||||||||||||||||||||||
|
Support monitoring sensor parameters |
Dissolved oxygen measuring range :0-20mg/L Turbidity range :0-1000NTU Conductivity range :0-5000uS/cm Ammonia nitrogen range :0-100mg/ UVCOD measuring range :0-400mg/L Wave height: Range: 0-25m Accuracy: <±3% Wave period: Range: 1.5-25s Wave direction: Range: 0-360 ° Resolution: 1° Ocean current velocity Measuring range 0-300cm /s Accuracy ±0.15cm/s Relative accuracy ±1% reading Flow Direction Resolution 0.01° |
||||||||||||||||||||||||||||||||||
|
Additional customization: visibility, weather |
|||||||||||||||||||||||||||||||||||
Application Scenarios
1. Marine resource development
2. Marine pollutant Monitoring
3. Meteorological monitoring
Packaging and Transportation
Reasonable design of packing, wooden box packing using scientific and reasonable structure design to ensure the safe transportation of goods
