Ocean buoys are mainly used to observe Marine hydrology, water quality and meteorological data, and provide support for Marine scientific research, offshore oil and gas resources development and national defense construction. Specifically, the ocean buoys have many types and application scenarios , for example, they are used for nuclear radiation monitoring, which is used to monitor the radioactivity level in the waters near the nuclear facilities, and send the data back to the ground measurement and control terminal through wireless communication, for meteorological monitoring : It can measure Marine weather, including wind speed, wind direction, sea wave height, water temperature and salinity, and provide important data for meteorological prediction and monitoring . for scientific research : Collect and record Marine environmental data to help scientists understand Marine ecosystems and provide a basis for environmental protection and resource management . Ocean buoys can also play a warning role, such as marking dangerous areas, demarcating special areas and guiding navigation routes. They can also be used in fishing operations, marking the boundaries of fishing grounds and providing the position of fishing nets . The color of the buoy body is customized according to IALA standard. In addition, the ocean buoy also integrates AI and autonomous power, and can be fixed to the bottom by anchor chain to act as an unmanned automatic ocean observation station.
Product Specifications
|
Diameter (mm) |
1200 |
1800 |
2300 |
2600 |
|
Focal plane (mm) |
1300 |
2000 |
2500 |
3000 |
|
Reserve buoyancy (kg) |
200 |
1401 |
2490 |
3000 |
|
Weight (kg)* |
250 |
850 |
1200 |
2000 |
|
Water line position (mm) |
1200 |
1200 |
1500 |
1500 |
|
Full height (mm) |
2500 |
3000 |
4000 |
4500 |
|
Name |
Ocean buoys |
||||||||||||||||||||||||||||||||||
|
Power supply system |
Storage battery |
12VDC80AH/80-200AH |
|||||||||||||||||||||||||||||||||
|
Solar panel |
12v/80W-400W |
||||||||||||||||||||||||||||||||||
|
Position indication |
Warning lights; GPS location; AIS |
||||||||||||||||||||||||||||||||||
|
Data acquisition |
4G, 5G, wireless communication, Lora, |
||||||||||||||||||||||||||||||||||
|
Support monitoring sensor parameters |
Dissolved oxygen measuring range :0-20mg/L Electrical conductivity range :0-5000uS/cm pH range: 0-14 pH, UVCOD range :0-400mg/L Chlorophyll range :0-500ug/L Wave height: Range: 0-25m Wave period: Range: 1.5-25s Accuracy: <±0.2 seconds Wave direction: Range: 0-360 ° Ocean current velocity Measuring range 0-300cm /s Resolution 0.1mm/s Accuracy ±0.15cm/s Flow Direction Range 0-360° Resolution 0.01° |
||||||||||||||||||||||||||||||||||
|
Additional customization: visibility, weather |
|||||||||||||||||||||||||||||||||||
Application Scenarios
1. Ocean Wind farm
2. Marine resource development
3. Ocean current research
Packaging and Transportation
Reasonable design of packaging, according to the size, characteristics and quantity of the product, design a reasonable carton, wooden box structure to ensure that the product is fully supported and protected inside the wooden box. Add pearl cotton to the equipment to mitigate and weaken the impact imposed on the object
